Applications

1.      360 Camera system

2.      Display connection system

3.      Mobile High-Definition Link(MHD)

4.      Controller Area Network(CAN)

5.      Rear seat entertainment system

6.      USB/LVDS interface connection

7.      Camera system

Features and Benefits

1.     Smaller size than HSD connector

2.     Lower cost than HSD connector

3.     Reliable design and performance for total solution –cable and board connector

4.     5 different coding and colors for different application or can be defined according to customer requirements

5.     Right angle and straight connector for different application

6.     Support high speed data transmission

7.     Excellent EMC shielding

8.     Operation Temp. -40˚C to +105˚C

Mechanical Performance

1.      Mating Force: 30N maximum

2.      Unmating Force: 110N maximum

3.      Durability: 25 cycles min.

Electrical Performance

1.     Contact resistance: 40mohm maximum change after stress test

2.     Dielectric Withstanding Voltage: 500 VDC minimum

3.     Insulation Resistance: 100 MΩ minimum

Product Environmental Compliance

RoHS2.0: Compliant

China RoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not Reviewed

Packing

        Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
