Redriver Type-C(DP Alt Mode)
|
Product Description: Type-C to Type-C with redriver Cable Assembly(DP Alt Mode)
Series: Type-C
Cable Length: 6meters
Signal and Power Wire Size: 30AWG and 22AWG
Lock to mating part: No
Plating: 30u” Au on terminals
Color: nature insulation of connector, black cable jacket
Environmental Compliance: RoHS
Flammability: cable VW-1, thermoplastic resin UL94V-0
(Note: The part number is only for reference. If you have requirement, please contact Amphenol for further confirming PN and drawing)
|
Redriver Type-C(DP Alt Mode)
Product Description: Type-C to Type-C with redriver Cable Assembly(DP Alt Mode)
Series: Type-C
Cable Length: 6meters
Signal and Power Wire Size: 30AWG and 22AWG
Lock to mating part: No
Plating: 30u” Au on terminals
Color: nature insulation of connector, black cable jacket
Environmental Compliance: RoHS
Flammability: cable VW-1, thermoplastic resin UL94V-0
(Note: The part number is only for reference. If you have requirement, please contact Amphenol for further confirming PN and drawing)
|
|
Applications
-
VR/AR
-
Camera
-
Monitor
-
Mobile phone
-
Notebook
Features
and Benefits
-
Use Tye-C
connector as interface
-
Support DP
Alt-mode to transmit 5.4Gbps high speed DP1.2 signal but not USB signal
-
Flexible
small size raw cable is easy to fold and convenient to use.
-
Support 6
meter cable length
|
