特征和优点

1.USB 2.0 transfer rate up to the maximum 480Mbps

2. Downward compatible with USB1.0/1.1 devices

3. Provide with both data transmission and charging

4. Provide blind mate

机械性能

         1. Mating Force and Unmating Force

             Condition: EIA 364-13, at a max rate of 12.5mm per minute.

             Requirement:

               Mating Force: 35N max.

               Unmating Force: USB-A:10N min initial.

         2. Durability

             Condition: EIA 364-09, at a max rate of 500 cycles per hour

         Requirement:

           USB A plug,1500 cycles. Micro-USB B plug, 10000 cycles.

         No physical damage

电气性能

         1. Contact Resistance

             30mohm max,+10mohm max change for post test

         2. Dielectric Withstanding Voltage 300VAC/min.

              No flashover, no spark over, no excess leakage and no breakdown.

          3. Insulation Resistance

              20M ohm min

          4. Contact Capacitance

               2PF max unmated per contact

          5. Differential  Impedance

               90 ohm + 15%

          6. Common Mode

               30+/-30% (Ohms)

          7. Cable Propagation Delay

              26ns Max, Adaptor: 1ns

          8. Cable Propagation Skew

              100ps for intra-pair Max

          9. Signal Attenuation

               USB Spec 2.0 section 7.1.17

               5.8dB max (at 400MHz)

               3.2dB max (at 200MHz)

               1.9dB max (at 96MHz)

环保要求

RoSH2.0:  符合

China : RoSH符合

REACH SVHC: 符合

无卤: 待评估
