Applications
1. Servers
2. Data Storage
3. Workstation
Features and Benefits
1. Smaller size connector and cable saves device space
2. Provide 8 channels signal transmission as per industry standard
3. Data speed: UPI1.0 11.2GT/s, SAS4.0 24Gbps, OpenCAPI 25Gbps and PCIe4.0 16GT/s per channel
4. Meet SAS4.0, Ultraport SlimSAS SFF-8654 specification
Mechanical Performance
Mating Force: 150N maximum
Unmating Force: 50N maximum
Rated durability cycles: 250 cycles minimum
Electrical Performance
1. Voltage: 30VDC per contact
80mohm max. initial, 20mohm maximum after stress test.
2.Dielectric Withstanding Voltage: 300 VDC minimum for 100 ms
3. Insulation Resistance: 10 MΩ minimum between adjacent pins
Signal Integrity
1. Mated Connector Impedance: 100+/-10% ohm
2. Common Mode Impedance: meet SAS4.0 specification
3. Insertion loss: meet SAS4.0 specification,
4. Maximum Crosstalk: meet SAS4.0 specification
Product Environmental Compliance
RoHS2.0: Compliant
ChinaRoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not Reviewed
Packing
Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
|
